* Not only for polymer powder but also various powder.
* Dissolving accuracy (+/-5%)
* Dissloving tank is more conpact than a conventional type.
* Less scattering powder by the ejector
* Improved operability with the touch screen.

Items		Specifications
Dissolving capacity		900 [L/h] (In dissovling time 20 minutes)
Dissolving tank capacity・material		Effective 300[L] SUS304
Hopper capacity		Effective 30・60 [L]　Transparent PVC or_ SUS304
Screw feeder	Capacity	maximum 1200 [g/min]
	Motor	90W (variable speed control by inverter)
Agitator	Revolution	200 /240 [rpm]　50 / 60 [Hz]
	Motor	0.2 [kW]
Line pump	Capacity	75 [L/min]×25 [m]
	Motor	0.75 [kW]
weight	Product weight	Approx 250[kg] (except for control panel)
	Operating weight	Approx 600[kg] (except for control panel)
Utility	Power source	AC 200/220V 50/60Hz 3phase
	Feed water	40 [L/min] ×0.2 [MPa] or_ over
	Instrument air	5 [L/min] ×0.49 [MPa]
Control method		PLC + Touch panel

PAD	–	L	90S	–	30	D	–	20	5
			[1]		[2]	[3]		[4]	[5]

Dissolving capacity	90S:900L/hr
Hopper capacity	30:30L 60:60L
Feed air system	D:Compressed air feed (w/ dry air) P:Dry air feed (w/o dry air) R:Dry air feed (w/ regulator)
voltage	20:200V 22:220V 40:400V 44:440V
Frequency	5:50Hz 6:60Hz
